ELEGOO Mercury XS Bundle

$225.00 $207.00

  • 360° all-round exposure
  • Dual function of washing and curing
  • Large washing volume of 7000ml
  • Easy and intuitive operation
  • UV Protection Cover
  • Wide Compatibility

Moving Out Sale while stock last

(Can not use coupon or points for discount)

In stock (can be backordered)

Add-on Resin
Out Of Stock
ELEGOO ABS-Like LCD UV-Curing Photopolymer Rapid Resin - grey $50.00 $47.50
ELEGOO ABS-Like LCD UV-Curing Photopolymer Rapid Resin - white $50.00 $47.50
Sale
ELEGOO Water Washable Rapid Resin LCD UV-Curing Resin - ceramic-grey $58.00 $55.10
Out Of Stock
Sale
ELEGOO Water Washable Rapid Resin LCD UV-Curing Resin - white $58.00 $55.10
No Return, No Refund Policy

Please note that purchases of 3D printers from Build It Full are subject to a no-return and no-refund policy. For technical support and warranty claims, please consult the respective manufacturer for guidance. Check out FAQ for more details.

SKU: ELE-P0009 Categories: , , ,

Description

  • 360° all-round exposure
  • Dual function of washing and curing
  • Large washing volume of 7000ml
  • Easy and intuitive operation
  • UV Protection Cover
  • Wide Compatibility









Dual function of washing and curing

ELEGOO Mercury XS contains 1 washing station and 1 post-curing station, with the dual function of cleaning and curing to remove uncured resin of 3D printed models and optimized your print quality, making your post-processing simple and efficient.

360° all-round exposure

2 adjustable L-shaped light bars and increased 4 LED lights under the 360° rotating turntable paired with Fresnel lens to emit UV light with a uniform wavelength of 405nm, ensuring that the model is evenly exposed from all angles.

A handheld UV lamp

Additionally, there is a handheld UV lamp to cure the interior or nooks and crannies of 3D printed parts for smoother surface and incredible print quality, also ideal for curing assembled models.

Large washing volume

With an 7000ml large capacity sealed water tank, you can directly wash large models printed or clean parts in batches, which offers substantial time savings and improves your productivity.

Friendly Tips: Mercury XS Bundle is perfect match with Mars 3 Pro 3D Printer and Saturn 2 3D Printer, but it need to remove the build plate’s handle before washing the Saturn 2’s prints.



Operation Instructions
1. After the model is printed, please clean and blow-dry the model before putting it into the machine.
2. If the model become yellow after curing, please reduce the curing time. Over curing will lead to a yellowish model.
3. Recommended ambient temperature is 0-40 degrees, and the ambient humidity temperature is 20%-50%.
4. Please do not use it for more than 40 minutes at a time to avoid overheating
5. Cure Time: If model diameter less than 30 mm, the curing time is recommended to be 2 minutes. If the surface structure of the model is complex, it is recommended to increase the curing time properly.
6. Special Notes: The washing function is not quite suitable for 3D models printed with water washable resin, which is better to be washed with running water.

Specification of Mercury XS WASH Machine
Control Method: Knob + Button
Rated Power: 12W
Input Voltage: 110V/240V 50/60Hz
Time Setting: 0-30mins
Machine Size: 255mm*155mm*385.5mm
Maximum Wash Volume: (with platform)180mm*121mm*153mm, (without platform)201mm*124mm*255mm
Machine Net Weight: 2.27kg

Specification of Mercury XS CURE Machine
Control Method: Knob + Button
Rated Power: 36W
Input Voltage: 110V/240V 50/60Hz
Time Setting: 0-30mins
Machine Size: 246mm*230mm*363.5mm
Maximum Curing Size: 200mm*260mm
Machine Net Weight: 2.4kg

Additional information

Weight 5.8 kg
Dimensions 30 × 52 × 31 cm
